Alkaline Battery - 4AG13


SPECIFICATIONS

  1. Model No. 4AG13
  2. Chemical system: Alkaline Zinc Manganese
  3. Nominal Voltage: 6V
  4. Nominal Capacity: 145 mAh (continuous discharge at 20¡Ó2¢J, under 0.22mA, discharge
    current to end point 3.6V)
  5. Battery weight: 9.97 gm
  6. Appearance: Metallic jacket in aluminum foil, cylindrical body
  7. Electrical Characteristics:
    • Open circuit voltage: ¡Ù6.05V
    • Discharge time (continuous discharge at 20¡Ó2¢J, under 7.5K£[, end point 3.6V)
      • New battery ¡Ù 190 hours.
      • After 12 months ¡Ù 170 hours.
  8. Cross reference: 4LR44, L1325
  9. Dimensions: unit in mm
